Computer Screen Display Hydraulic Universal Tester

Computer Screen Display Hydraulic Universal Tester

  • Min.Order Quantity: 1 Set
  • Supply Ability: 100 Sets per Month
  • Port: China Port
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
Verified Supplier Jinan Zhongchuang Industry Test Systems Co., Ltd
| Factory
Experience:2010-03-15
Visit Factory
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Place of Origin:  China
  • Brand Name:  zhongchuang
  • Model Number:  WEW-100B
  • Weight: 1700.000 kg
Details :

The computer screen display hydraulic universal testing machine has different models, including WEW-100B, WEW-300B, WEW-600B,
WEW-1000B, WEW-1000D, we also have electro-hydraulic servo hydraulic universal testing machines.

Details of 10T  Computer Screen Display Hydraulic Universal Testing Machines as following:

Main Technical Index

Model: WEW-100B
Max test force: 100kN
Measuring range of test force:4%-100%FS
Resolution of test force: 0.01kN
Tensile space: 550mm
Compressive space: 380mm
Clamping type: manual tighten
Clamping diameter of round specimen: Φ6-26mm
Clamping thickness of flat specimen: 0-15mm
Max clamping thickness of flat specimen: 70mm
Diameter of shear specimen: 10mm
Size of up and down pressure plate: Φ160mm(or 204*204mm)
Net weight:1700kg


  • Place of Origin:  China
  • Brand Name:  zhongchuang
  • Model Number:  WEW-100B
  • Weight: 1700.000 kg
