- Place of Origin: China
- Brand Name: zhongchuang
- Model Number: ZCWD-S50N, 100N, 200N, 500N, 1000N, 2000N, 5000N
- Weight: 150.000 kg
| Details : | |
The computer screen display hydraulic universal testing machine has different models, including WEW-100B, WEW-300B, WEW-600B, |
- Place of Origin: China
- Brand Name: zhongchuang
- Model Number: ZCWD-S50N, 100N, 200N, 500N, 1000N, 2000N, 5000N
- Weight: 150.000 kg
The electronic universal testing machine is used in tension, compression, bending, sheer, tear, peel, tensil strength,
yield strength, elongation, modulus of elasticity, compression and bending test of mechanical performance of metal,
non-metallic and composite material.
Main Technical Specifications of Digital Display Electronic Universal Testing Machine
Model: ZCWD-S50N, 100N, 200N, 500N, 1000N, 2000N, 5000N
Grade of accuracy: be superior to grade 1
Measuring range of test force: 1.0%~100%FS
Accuracy of force value: be superior to ±1%
Resolution of force value: 1/200000
Error of diplacement indicating value: within ±0.5% of indicating value
Range of measuring speed: 1～500mm/min
Measuring space:1000mm(optional)
Size of testing machine: 560x320x1800mm
Power supply: AC 220V±10% 50Hz，0.75kw
Weight of testing machine: about 150kg
